● 1/3.3" 2MP CMOS
● H.265+, H.265/H.264, dual stream
● Supports backlight compensation, highlightcompensation, and 3D digital noise reduction
● Supports image flip, mirror, and rotation
● Supports dual light and smart dimming
● Supports external TF card, WiFi or 4G communication
● Supports 1-channel serial port, 1-channel IO input and 1-channel IO output
● Supports accurate human detection and vehicle detection; Applicable to scenarios including electronic fence, intrusion detection and on-duty detection etc.
● Supports privacy mask
● Supports voice intercom, voice broadcast, custom voice
● ONVIF Profile S, T, G, M
● Plug-in free for mainstream browsers
● Support Browser-based CMS
| Model | E7520G-G2 |
| Main Chip | 37X，built-in 0.5T computing power |
| Image Sensor | 2MP, 1/3.3" CMOS |
| Image Output | Main stream 30FPS（1920*1080，1280*720 |
Sub stream 30FPS（640*360，352*240 | |
Image effects: Auto white balance, digital wide dynamic range, backlight compensation, and adjustable hue/brightness/contrast/saturation/sharpness | |
| Audio | Standard: 1-channel MIC input, 1-channel built-in amplifier output (8Ω1W/4Ω2W |
| G.711 codec; supports two-way audio intercom, audio-video synchronization, and echo cancellation | |
Networ | 1 x RJ45 10/100 M self-adaptive Ethernet port |
| TF | 1× TF card slot, supports up to 512 GB |
| WIFI（Optional） | Supports external Wi-Fi 4/6 module, dual-band, 802.11b/g/n/ax |
4G（Optional） | Supports external 4G communication module |
Reset Key | Supports hardware reset |
| IO Input/0utput | 1 x Input, 1 x Output |
| Light Board Interface | Supports dual light and smart dimming |
| Indicator | Supports network connection status LED |
| Network Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,NTP,UPnP,SMTP,IGMP,802.1X,IPv4, IPv6,UDP,SSL/TLS,SNMP,ARP,WebSocket,ONVIF |
| Intelligent Applications | Human & vehicle classification (including non-motor vehicles), boundary detection, intrusion detection, region entering detection, region exiting detection and sound alarm linkage |
| Power | DC 12V |
| Operating Conditions | -30℃～+65℃(-22°F to +149°F), ≤95%RH |
| Dimension | Board: 38 x 38 mm, board thickness 1.6 mm |
